24V/20A STD YPOWER CHARGER - 3 BANKS
24V/20A STD YPOWER CHARGER - 3 BANKS
CRISTEC YPOWER BATTERY CHARGER 24V / 20A
Specifications:
Model |
24V / 20A |
Recommended battery bank (Pb) |
200 – 300Ah |
Input current consumption 230/115VAC |
2.9 / 5.9 A |
Recommended power for a generator |
700 W |
Total rated current (+/-7%) Rated power |
20A / 570W |
Dimensions (length, height, depth) |
289 x 195 x 106 mm |
Weight |
3.5 kg |
About Cristec YPower Chargers
With more than 150,000 HF battery chargers installed worldwide, CRISTEC is proud to present its fifth generation of HF chargers: YPOWER range.
Indeed, being robust, reliable and efficient, the latter will offer you professional use of quality and comfort of use thanks to its multi-output function.
YPOWER battery chargers are also compatible with a DC 144V (121V–169V) or a DC 288V (247V–346V) input network – see datasheet
SILENT OPERATING
CRISTEC is the only manufacturer to offer chargers with natural convection (without fan) up to 40A * included (* in 12V; 20A in 24V).
This specificity gives them totally silent operation and an optimized lifespan.
It is therefore possible to install them anywhere on board, including under a berth.
The more powerful models, 12V / 60A and 24V / 30A, have a controlled fan.
In other words, the fan will only be in operation at the very start of charging (Boost phase) and/or when the ambient temperature is high.
THERMAL PERFORMANCE
- Rated charge up to +60°C with no derating
- can be installed in an engine room
- Model 12V/40A Ignition protected according to standards SAE J1171 and ISO8846
EASY CONNECTION
Quick, reliable and friendly mounting
AC & DC plug connectors included
5-STAGE CHARGING PROFILE
Boost : charges batteries to 80% of full charge
Absorption : slowly completes remaining charge to 100%
Floating : maintains battery charge
Automatic refresh : prevents sulphation and revitalizes batteries, selectable by internal switch
Reboost : new automatic Boost phase if batteries demand needs it.
Power-supply mode also available.
IU mode by inhibiting the BOOST using internal switch.
ADAPTATIVE CHARGE
Presence of a custom-made and simultaneous recharge of 3 battery banks, including one dedicated to the motor battery.
YPOWER chargers are compatible with all types of batteries:
- Opened classic lead
- Sealed, Gel or AGM
- Spiral sealed
- Lithium Iron Phosphate ( LiFePO4 ) with BMS
APPLICATIONS
YPOWER AC-DC battery chargers adapt to different markets and applications:
- Professional marine : naval, service boat, fishing boat, passenger boat, tug, barge, barge, lighthouse and beacon.
- Recreational marine : yachting, sailing boat, motor boat, electric boat, catamaran, speedboat, etc.
- Mobile :
- Emergency vehicles : firemen, ambulance, rescue, depollution, etc.
- Recreational vehicles : motorhome, golf course, etc.
- Special vehicles : surveillance, transport of animals, Van, public works etc.
- Industry : automated cleaning, on-board camera, recognition robots, telecommunications, etc.
- Wind-powered : landsites
- Solar : isolated sites
